Intel® Pentium® 4 Socket LGA 775
ITEM #QTY. PART NO. DESCRIPTION
A 1 LPGA 775 Prescott Socket T Representation
B 1 storm-assy2
C 1 STORM-HOLD-DOWN-R1Storm Universal hold-down plate
D 2 1-4-straightx3-8-barb 1/4" NPSM Barb fitting - 3/8" & 1/2" supplied
E 2 O-RING-9557K473 1-4'" NPSM barb fitting O-Ring
F 4 6-32-Acorn-nut
G 4 SPRING6 70927compressed-to-0337
H 8 12SWS0444 NYLON SHOULDER WASHER
I 4 6-32-nut 6-32 nut
J 4 LOCK-WASHER#6
K 8 FW140X250X0215FB BLKblack fiber washer
L 4 6-32X1.750 6-32 x 1 3-4" philips screw
F
H
G
H
C
I
J
K
K
L
D
E
A
B
Inlet
