14 OM-DS-SC
Parts List
Key Description Part #
1 Upper Cavity Drain Hose 088847
2 Motor Assembly 096740
3 Timer 096826
4 Knob, Timer 123100
5 PC Board, Light and Timer 130457
6 Bracket, Board Mtg 096888
7 Steamer Control Board 102222
8 Capacitor, 6 mfd 096812
9 Shield, Motor Drip 119844
10 Nut, Rotary Shaft Seal 101145
11 Nut, Keps 6-32 071289
12 Harness, Upper Control 130450
13 Post, PC Board Mtg 099901
14 Screw, 6-32 069777
15 Jumper, Voltage Select 100959
16 Harness, Spray Vavle 137834
17 Cable Clamp 087958
18 Nut, 10-32 071256
19 Nut, 8-32 002632
Key Description Part #
31 Valve, Safety 143470
32 Manifold Fitting 099249
33 Gasket 099250
34 Nut, 1/4-20 012940
35 Tee 013201
36 Solenoid Valve 113014
37 Nipple, 3/8 013202
38 Connector 054493
39 Tube, Upper 100551
40 Elbow 042364
41 Tee 100553
42 Tube, Supply 100552
43 Lower Cavity Drain Hose 088848
Steamer Cavity Only
