9
Operation
Controls
COMpONENT DESCrIpTION
1. SELECTOR SWITCH - controls power to the oven
fan speed and selects Cool Down mode.
2. OVEN READY LIGHT - when lit, indicates heater
operation. When the light goes out, the oven has
reached operating temperature.
3. OVEN SOLID STATE THERMOSTAT - allows an in-
finite selection of temperatures from 200-500ºF (95-
260ºC).
4. COOK TIMER - used to time the length of the cook-
ing operation. When the set time expires an alarm
sounds.
5. GRIDDLE SOLID STATE THERMOSTAT - allows an
infinite selection of temperatures from 0-400ºF (0-
200ºC). Also controls power to the griddle.
6. GRIDDLE READY LIGHT - when lit, indicates heat-
er operation. When light goes out, the griddle has
reached operating temperature.
7. CIRCUIT BREAKER SWITCH - used to turn power to
the unit ON or OFF.
8. FRENCH BURNER THERMOSTAT - allows the pow-
er selection of the french burners from LOW to HIGH.
Also control power to the french burners.
9. FRENCH BURNER READY LIGHTS - when lit, in-
dicates heater operation. When light goes out, the
applicable french burner has reached operating tem-
perature.
OVEN CONTrOL OpErATION
1. Turn the SELECTOR SWITCH (1) to OVEN ON.
2. Set the COOK THERMOSTAT (3) to the desired tem-
perature.
3. Preheat the oven until the OVEN READY (2) light
goes out, indicating the oven has reached operating
temperature.
4. Load product into the oven. Set the COOK TIMER (4)
to the desired time.
5. When the buzzer sounds, remove the product from
the oven. Turn the timer to OFF to silence the alarm.
6. Turn the SELECTOR SWITCH (1) to OVEN OFF.
GrIDDLE CONTrOL OpErATION
1. Turn the GRIDDLE THERMOSTAT (5) to the desired
temperature.
2. Preheat the griddle until the GRIDDLE READY (6)
light goes out, indicating the griddle has reached op-
erating temperature.
3. Turn the GRIDDLE THERMOSTAT (5) to 0º to power
off the unit.
FrENCh BUrNEr CONTrOL OpErATION (if appli-
cable)
1. Place a pot or pan on the burner.
2. Turn the applicable FRENCH BURNER THERMO-
STAT (8) to the desired setting, HI being the hottest
and LO being the coolest.
wArNING!!
DO NOT run the french burners without a load.
Turn the thermostat to the OFF position when
not in use.
