Page 10: Ctb-gfb & ctbr-gfb, Figure 2
8
Operation
Figure 2
Controls
LEFT GRIDDLE THERMOSTAT
RIGHT GRIDDLE THERMOSTAT
OVEN
OFF
COOL
DOWN
HIGH
FAN
LOW
FAN
HEATING
THERMOSTAT
TIMER
CIRCUIT
BREAKER
DISCONNECT BEFORE SERVICING
www.blodgett.com
5
6
6
2
1
3
4
7
CTB-G & CTBR-G
RIGHT GRIDDLE THERMOSTAT
OVEN
OFF
COOL
DOWN
HIGH
FAN
LOW
FAN
HEATING
THERMOSTAT
TIMER
CIRCUIT
BREAKER
DISCONNECT BEFORE SERVICING
www.blodgett.com
REAR
FRONT
5
6
2
1
3
4
7
9
9
8
8
CTB-GFB & CTBR-GFB
