$70654#8VHU·V#*XLGH
2-5
0HQX#1DYLJDWLRQ#8VLQJ#WKH#7HUPLQDO#,QWHUIDFH
As a default, Omega’s terminal interface is configured to use a DEC
VT100 or ANSI terminal, or an equivalent terminal emulator program.
'LVSOD\LQJ
6XEPHQXV
At startup, Omega highlights the first item on the main menu
(Figure 2-1 on page 2-2).
To select a menu option:
1. Press the up (
↑
), down (
↓
), left (
←
), or right (
→
) arrow key to
highlight an option.
2. Press .
(QDEOLQJ#RU
'LVDEOLQJ#DQ
2SWLRQ
Omega displays the enabled option in bold and precedes it with a >
symbol. For example, to view information about a port:
1. Select Port status and configuration from the main
menu to display a list of ports.
2. Select a port number, for example, Port 11, by pressing the up
arrow key to highlight it; and then press to display its
configuration information:
Figure 2-2 Sample Port Configuration Menu, Terminal Interface
Port Configuration Menu
Port 11
Link State:Offline
Port State:Enabled
Please select an option:
> Enable this port
Disable (partition) this port
> Auto negotiate
Full duplex
Half duplex
> Store-and-forward
Cut-through (for 100MBPS operation)
Port name
Return to Port Status Menu ...
Enabled options
