Switch Configurations
4-2
The Switch in Workgroup Configurations
Figure 4-2 shows how the different switches fit into a large corporate
network with a Fast Ethernet infrastructure. A switch is located on
each floor and servers are centralized in one room.
Figure 4-2 Switches in Workgroup Configurations
Legend
Shared 10/100 Mbps Link
Dedicated 10 Mbps Link
Dedicated 100 Mbps Link
10/100 Mbps Link
RS-232 TERMINAL POR T STATUS
10BASE-T / 10 0BASE-TX FAST ETHERN ET SWITCH
PORT ACTIVITY 10BASE-T / 10 0BASE-TX
AT-8124XL
Hub
Workstations
AT-8118
Hub
Workstations
Workstations
AT-8118 with
AT-A11 Fiber
Servers
Servers
Uplink
FORMULA 8200
Switch with TX/FX Ports
Server
Backbone
