AT-MR420TR and AT-MR820TR Installation Guide
21
10Base-T connections require Category 3, 4, or 5. In most cases, if a
cable type is flat, it is typically untwisted and can cause problems.
Generally, cable that is more or less round in section, gives better
results.
Hub to MAU Wiring. The most typical TP cable for the AT-MR420TR/
AT-MR820TR Micro Repeaters is TP Hub to TP transceiver Data
Terminal Equipment (DTE).
To configure your own cables, see Appendix A, “Technical
Specifications.”
MRx20TR(STP/UTP)_BookA Page 21 Thursday, April 3, 1997 5:24 PM
