AT-MR420TR and AT-MR820TR Installation Guide
17
10Base-T Network Specifications
Table 2 provides an overview of the IEEE 802.3 specifications for
10Base-T network configurations using thick, thin, and twisted-pair
wiring.
AUI Port
The AUI port is a 15-pin D-sub female connector, located on the back
panel. This AUI backbone port connects the repeater to the network
using a standard AUI drop cable. See Figure 9. Alternatively, you can
fit any of a variety of Allied Telesyn’s 802.3 transceivers into this port
should you select a different medium such as fiber optics.
Table 2: IEEE 802.3 Network Specifications
10Base-T 10Base2 10Base5
Media Twisted Pair
Cable
Thin Coaxial
Cable
Thick Coaxial Cable
Topology Star, Tree Bus Bus
External Devices Network
Adapter Card
Network
Adapter Card
Network Adapter
Card and External
Transceiver
Maximum
Segment Length
100 meters
(328 ft.)
185 meters
(605 ft.)
457 meters
(1,500 ft.)
Maximum
Devices per
Segment
_ 30 100
Maximum
Devices per
Network
_ 1,024 1,024
