AT-S63 Management Software Menus Interface User’s Guide
Section II: Advanced Operations 311
Displaying ACLs
To display the ACLs on a switch, perform this procedure:
1. From the Main Menu, type 7 to select Security and Services.
2. From the Security and Services menu, type 4 to select Access Control
Lists.
The Access Control Lists (ACL) menu is shown in Figure 92 on page
303.
1. From the Access Control Lists (ACL) menu, type 4 to selection Show
ACLs.
An example of the Show ACLs window is illustrated in Figure 96.
Figure 96. Show ACLs Menu
This menu is for viewing purposes only. To modify an ACL, refer to
“Modifying an ACL” on page 306. The columns in the display are
explained here:
ˆ ACL ID - The ACL’s ID number.
ˆ Description - The description of the ACL.
ˆ Active - The status of the ACL. An ACL is deemed active if it is
assigned to at least one port. An ACL is deemed inactive if it is not
assigned to any ports.
Allied Telesyn AT-9424T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Show ACLs
Number of ACLs: 12
ID
Description Active
-------------------------------------------------------
1
IP - deny Yes
2 HTTP - permit Yes
3 TCP - deny No
4 Src22.49 - deny Yes
5 P-149.22.22.22 Yes
6 Dst22.50 Yes
7 ARP packets - deny No
D - Detail ACL Display
N - Next Page
U - Update Display
R - Return to Previous Menu
Enter your selection?
