AT-S63 Management Software Menus Interface User’s Guide
Section I: Basic Operations 187
Creating a Port Mirror
To create a port mirror, perform the following procedure:
1. From the Main Menu, type 1 to select Port Configuration.
2. From the Port Configuration menu, type 6 to select Port Mirroring.
The Port Mirroring menu is shown in Figure 50.
Figure 50. Port Mirroring Menu #1
3. From the Port Mirroring menu, type 1 to select Enable/Disable.
The following prompt is displayed.
Enter Enable(E)/Disable(D):
4. Type E to enable the feature.
New options are added to the Port Mirroring menu, as shown in Figure
51.
Figure 51. Port Mirroring Menu #2
5. Type 2 to select Mirror-To (Destination) Port.
Allied Telesyn AT-9448T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Mirroring
1 - Enable/Disable .................... Disabled
R - Return to Previous Menu
Enter your selection?
Allied Telesyn AT-9448T/SP - AT-S63
Marketing
User: Manager 11:20:02 02-Mar-2005
Port Mirroring
1 - Enable/Disable ...................... Enabled
2 - Mirror-To (Destination) Port ........ None
3 - Ingress (Rx) Mirror (Source) Ports .. None
4 - Egress (Tx) Mirror (Source) Ports ... None
R - Return to Previous Menu
Enter your selection?
