Stand-Alone – Converteon™ Module Configured for Link Test
Figure 49 on page 98 shows a stand-alone configuration for a
Converteon™ line card (Module A) that has been configured for the Link
Test mode. Refer to “Link Test” on page 44 for configuring the module of
the Link Test mode. Module A is connected to an AT-8524M (Switch 1)
with a copper cable and to an AT-8516F/SC (Switch 2) with a dual fiber
cable.
Table 27 shows the Link (LK) LED status for each of the ports involved
when the cables are connected and disconnected from Module A's ports.
Table 27. Stand-Alone – Converteon™ Module in Link Test Mode
Network
Device
Port
Link
Converteon™ Module Cable Status
All Cables
Connected
Copper Cable
Switch 1 to
Module A -
Disconnected
Module A
Transmit/
Receive
Fiber Cable
Disconnected
Port
LINK
Status
Switch 1 Copper
LK LED ON OFF ON
Converteon™
Module A
Copper
LK LED ON OFF ON
Fiber
LK LED ON ON OFF
Switch 2 Fiber
LK LED ON ON OFF
