Converteon Media Converter Line Cards Reference Guide
51
“X” means the DIP switch position could be either ON or OFF.
Table 13 lists the positions of the Port Configuration DIP Switch 2 for the
twisted pair port on the AT-CM20x Series and AT-CM212x/1 Series line
cards.
“X” means the DIP switch position could be either ON or OFF.
OAM Visible ON ON OFF X
Link Test (default) OFF OFF OFF X
Manufacturing Default Settings OFF OFF OFF OFF
Table 13. AT-CM20x Series and AT-CM212x/1 Series – Port Configuration
DIP Switch 2 Positions
Operating Mode DIP 1 DIP 2 DIP 3 DIP 4
Auto MDI-X Enable (default) X OFF X X
Auto MDI-X Disable X ON X X
Manufacturing Default Settings OFF OFF OFF OFF
Table 12. AT-CM20x Series and AT-CM212x/1 Series – Diagnostic Mode
DIP Switch 1 Positions
Operating Mode DIP 1 DIP 2 DIP 3 DIP 4
