Chapter 1: Converteon™ Fast Ethernet and Gigabit Ethernet Line Cards
18
AT-CV101 Fiber Optic Dual ST 50/125 or
62.5/125 micron
Multi-Mode
1
100 Mbps 2 kilometers
(1.24 miles)
Copper RJ-45 Twisted-Pair 100 Mbps 100 meters
(328 feet)
AT-CV102 Fiber Optic Dual SC 50/125 or
62.5/125 micron
Multi-Mode
1
100 Mbps 2 kilometers
(1.24 miles)
Copper RJ-45 Twisted-pair 100 Mbps 100 meters
(328 feet)
AT-CV102/1 Fiber Optic Dual SC 9/125 micron
Single-Mode
2
100 Mbps 40 kilometers
(24.8 miles)
Copper RJ-45 Twisted-pair 100 Mbps 100 meters
(328 feet)
AT-CV102/2 Fiber Optic Dual SC 9/125 micron
Single-Mode
2
100 Mbps 15 kilometers
(9.4 miles)
Copper RJ-45 Twisted-pair 100 Mbps 100 meters
(328 feet)
AT-CV1KSS SFP Varies by SFP
transceiver Varies by SFP
transceiver
2
1.25 Gbps Varies by SFP
transceiver
SFP Varies by SFP
transceiver Varies by SFP
transceiver
3
1.25 Gbps Varies by SFP
transceiver
AT-CM70S SFP Varies by SFP
transceiver Varies by SFP
transceiver
3
1.25 Gbps Varies by SFP
transceiver
Copper RJ-45 Twisted-Pair 10 Mbps or
100 Mbps 100 meters
(328 feet)
T1/E1 RJ-48 Twisted-Pair n/a n/a
RS-232
Console Mini-DIN RS-232 Serial n/a n/a
1. Do not use single-mode fiber optic cable with these ports.
2. SFP transceiver sold separately.
Table 1. Basic Line Card Configurations
