SC Type Connectors
Dual SC
Connector
The fiber optic cable, as shown in Figure 44, is used to connect to the dual
SC connectors in various Converteon™ line cards.
Figure 44. Dual SC Connector Cable
Simplex SC
Connector
The fiber optic cable, as shown in Figure 45, is used to connect to the
simplex SC connectors in various Converteon™ line cards.
Figure 45. Simplex SC Connector Cable
