6.13 AT-9800/SwitchBlade Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
• Notes
6.13.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Tagged Ports This is a list of the tagged member ports of the VLAN.
Untagged Ports This is a list of the untagged member ports of the VLAN.
Type
This indicates the type of the VLAN.
• Port-based
• IP subnet-based
• Protocol-based
• MAC address-based
• Limited protocol-based
Status
This indicates the status of the VLAN.
• dynamic
• static
6.13.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name (cannot be
modified)
- Alphanumeric characters
- Underscore ("_")
- Dash ("-")
Note - VLAN names must contain at least one (1)
alphabet character.
Note - "ALL" is a reserved word and cannot be used as
a VLAN name.
1 - 15 characters
If the software
release version
is 2.7.1 or higher:
1 - 32 characters
AlliedView™-EMS 4.0.1 VLAN MANAGER USER’S GUIDE Page 58 of 72
