Operation Mode

(cannot be

modified)

- Normal

- Private

- Protected

6.7.3 Notes

•

When importing the default VLAN, VLAN Manager disregards the values specified
for Untagged Ports.

•

During an Import VLAN operation, VLAN Manager will ignore the values specified

for the Uplink Port and Private Ports fields if the value specified for the Operation

Mode field is "Normal" or "Protected".

•

When two Private VLANs specify the same Uplink port (Uplink port is untagged for
the first Private VLAN and tagged for the second Private VLAN), modifying the

Private VLAN that has the untagged Uplink port will result in the error message:

" already has an uplink, more than one Uplink is not permitted."

All ports in that Private VLAN will then be deleted.
