6.6 AT-8500 Series

Topics:

VLAN Information Window

Add/Modify VLAN Dialogs

Notes

6.6.1 VLAN Information Window

The VLAN Information Window displays the following attributes for each VLAN definition:

Column Name

Description

Name

This is the name of the VLAN.

Identifier

This is the unique identifier of the VLAN.

Tagged Ports

This is a list of the tagged member ports of the VLAN.

Untagged Ports

This is a list of the untagged member ports of the VLAN.

Status

This indicates the status of the VLAN.

active

not in service

not ready

create and go

create and wait

destroy

6.6.2 Add/Modify VLAN Dialogs

The Add/Modify VLAN Dialogs have the following Input Fields:

Input Field

Valid Values

Length

Name

- Alphanumeric characters

- Underscore ("_")

- Dash ("-")

Note

- VLAN names must contain at least one (1)

alphabet character.

1 - 20 characters

Identifier (cannot
be modified)

1 - 4094

-

6.6.3 Notes

The current firmware version does not allow VLAN Manager to distinguish between
Protected VLANs, Mac-based VLANs and standard Port-based VLANs. As a result,

AlliedView™-EMS 4.0.1 VLAN MANAGER USER’S GUIDE

Page 44 of 72
