6.2 AT-8000GS Series
Topics:
• VLAN Information Window
• Add/Modify VLAN Dialogs
• Notes
6.2.1 VLAN Information Window
The VLAN Information Window displays the following attributes for each VLAN definition:
Column Name Description
Name This is the name of the VLAN.
Identifier This is the unique identifier of the VLAN.
Access (Untagged Ports) This is a list of the untagged member ports of the VLAN whose
VLAN membership mode is set to access.
Trunk (Tagged Ports)
This is a list of the tagged member ports of the VLAN whose
VLAN membership mode is set to trunk.
Trunk (Untagged Ports)
This is a list of the untagged member ports of the VLAN whose
VLAN membership mode is set to trunk.
General (Tagged Ports)
This is a list of the tagged member ports of the VLAN whose
VLAN membership mode is set to general.
General (Untagged Ports) This is a list of the untagged member ports of the VLAN whose
VLAN membership mode is set to general.
Forbidden Ports This is a list of the forbidden member ports of the VLAN.
6.2.2 Add/Modify VLAN Dialogs
The Add/Modify VLAN Dialogs have the following Input Fields:
Input Field Valid Values Length
Name
- Alphanumeric characters
- Special characters except the following:
• Hash Sign ("#")
• Period (".")
• Colon (":")
• Right Angle Bracket (">")
• Question Mark ("?")
1 - 32 characters
Identifier (cannot
be modified)
2 - 4093 -
