Overview
44
Powering On the
Provider Unit
If you have rack mounted the AT-MC605 Provider unit, the host
equipment, AT-MCR12 rackmount chassis, is must be powered on as
well.
Warning
The QUALIFIED SERVICE PERSONNEL must verify that the
AT-MCR12 rackmount chassis power cord is connected to the
socket provided with the ground conductor.
If the power cord is not connected, the QUALIFIED SERVICE
PERSONNEL must install a permanent ground connection using the
bond stud on the rear panel of the AT-MCR12 rackmount chassis.
For detailed information on how to power on the AT-MCR12 rackmount
chassis, refer to the AT-MCR12 Media Converter Rackmount Chassis
Installation Manual.
If you have installed a stand alone AT-MC605 Provider unit, power on the
unit using the power adapter provided, as shown in Figure 20.
Figure 20. Power On The Subscriber Unit
12 VDC
