Overview
22
Status LEDs
The AT-MC605 VDSL Ethernet Extender features the status LEDs and are
defined in Table 5.
Table 5. Front Panel Status LEDs
LED Color Description
PWR
GREEN Power is applied to the unit.
OFF Power is not applied to the unit.
10/100Base-TX Port
LINK/
ACT
Solid GREEN A link has been established on the port.
Blinking
GREEN Network traffic is being transmitted and/or
received.
OFF A link has not been established.
100M
Solid GREEN Port is linked at 100 Mbps.
OFF Port is linked at 10 Mbps when LINK/ACT
LED is solid or blinking GREEN.
VDSL LINE Port
SCBR/
PROV
Solid GREEN Unit is configured as a Subscriber Unit
(SCBR)
OFF Unit is configured as a Provider Unit
(PROV)
LINK
Slow Blinking
GREEN VDSL is idle when blinking occurs
approximately 1 time/sec.
Fast Blinking
GREEN VDSL is in the training or handshake
mode when the blinking occurs
approximately 3 times/sec.
Solid GREEN VDSL has established a connection with
its link partner.
Rapid Blinking
GREEN VDSL activity is occurring when the
blinking occurs approximately 6 times/
sec.
OFF VDSL link is not established.
