Figure 6: at-x230-18gp back panel – Allied Telesis AT-x230-18GP User Manual
Page 23
AT-x230-10GP and AT-x230-18GP Switches Installation Guide
13
Figure 6 illustrates the back panel of the AT-x230-18GP Gigabit Ethernet
Switch.
F
IGURE
6. AT-
X
230-18GP
BACK
PANEL
Power connector
Power cable hook
Power cable hook mount
