Chapter 1: Overview

12

Front and back panels on the AT-x230-18GP Switch

Figure 5 illustrates the front panel of the AT-x230-18GPGigabit Ethernet
Switch.

F

IGURE

5. AT-

X

230-18GP

FRONT

PANEL

MAC Address Label

10/100/1000Mbps PoE+ ports

Link/activity/speed LED

PoE status LED

SFP slots

Upper (left), lower (right)

SFP LEDs:

ecofriendly button

SD card slot

MAC address label

Console port

SD/Fault/Power LEDs
