ENGLISH
✤
Miscellaneous Information:
Connecting the CAM with other Devices
107
107
Connecting the CAM to a VCR
You can connect the CAM to VCR to copy the recorded files to the
video tape.
1. Connect the Video/Audio cable to
the AV Output Jack of the CAM.
2. Connect the Video/Audio cable to
the external input terminal of your
VCR set by matching the colors of
the terminals.
3. Connect the Video/Audio cable to
the Video line
Output and TV line Input.
4. Select the ‘Input’ on the TV, VCR or
the remote control of TV.
Note
✤ If TV set has no Line Input, you cannot view the output screen of
the CAM.
1
2
3
4
5
6
7
8
9
10
ALARM IN
ALARM OUT
ALARM RESET
GND
TRIGGER OUT
TAPE END OUT
SERIES OUT
GND
SERIES IN
1 SHOT REC IN
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
IN
OUT
OUT
IN
Line Input
Line Output
Line Input
