NR01 Four-Component Net Radiation Sensor
2: Scaling Array (A*Loc+B) (P53)
1: 1
Start Loc [ SR01_up ]
2: 65.146 A1 ;SR01 up
3: 0 B1
4: 75.18 A2 ;SR01 down
5: 0.0 B2
6: 117.65 A3 ;IR01 up
7: 0.0 B3
8: 121.95 A4 ;IR01 down
9: 0.0 B4
;Measure the IR01 temperature
3: Full Bridge w/mv Excit (P9)
1: 1
Reps
2: 32 50 mV, 50 Hz Reject, Slow, Ex Range**
3: 32 50 mV, 50 Hz Reject, Slow, Br Range**
4: 3* DIFF Channel
5: 1 Excite all reps w/Exchan 1
6: 4200 mV Excitation***
7: 5 Loc [ IR01_TC ]
8: 1 Multiplier
9: 0.0 Offset
4: Temperature RTD (P16)
1: 1
Reps
2: 5 R/R0 Loc [ IR01_TC ]
3: 5 Loc [ IR01_TC ]
4: 1.0 Multiplier
5: 0.0 Offset
;Also create a temperature in K for use in optional online
;calculation of fluxes
5: Z=X+F (P34)
1: 5
X Loc [ IR01_TC ]
2: 273.15 F
3: 6
Z Loc [ IR01_TK ]
;In this example just output the scaled flux measurements
6: If time is (P92)
1: 0
Minutes (Seconds --) into a
2: 60 Interval (same units as above)
3: 10 Set Output Flag High (Flag 0)
7: Real Time (P77)
1: 0220
Day,Hour/Minute (midnight = 2400)
8: Average (P71)
1: 6
Reps
2: 1 Loc [ SR01_up ]
Note: Proper entries will vary with program and *input channel usage. For other loggers use:
** 25 mV range for CR10X, 50 mV for 21X and CR7
*** 4200 mV for 21X and CR7, 2100 mV for CR10X
