NR01 Four-Component Net Radiation Sensor
TABLE 4.3-1. Datalogger Connections for Differential Measurement, when using a 4WPB100
Wire Label Color (cable 1) CR10X CR1000, CR23X, CR7
Pyranometer Up Sig Red Differential Input (H) Differential Input (H)
Pyranometer Up Ref *Blue Differential Input (L) Differential Input (L)
Pyranometer Down Sig White Differential Input (H) Differential Input (H)
Pyranometer Down Ref *Green Differential Input (L) Differential Input (L)
Pyrgeometer Up Sig Brown Differential Input (H) Differential Input (H)
Pyrgeometer Up Ref *Yellow Differential Input (L) Differential Input (L)
Pyrgeometer Down Sig Purple Differential Input (H) Differential Input (H)
Pyrgeometer Down Ref *Grey Differential Input (L) Differential Input (L)
Shield Shield G
*Jumper to AG or with user supplied wire.
TABLE 4.3-2. Datalogger Connections for Single-Ended Measurement, when using a 4WPB100
Wire Label Color (Cable 1) CR10X CR1000, CR23X, CR7
Pyranometer Up Sig Red Single-Ended Input Single-Ended Input
Pyranometer Up Ref Blue AG
Pyranometer Down Sig White Single-Ended Input Single-Ended Input
Pyranometer Down Ref Green AG
Pyrgeometer Up Sig Brown Single-Ended Input Single-Ended Input
Pyrgeometer Up Ref Yellow AG
Pyrgeometer Down Sig Purple Single-Ended Input Single-Ended Input
Pyrgeometer Down Ref Grey AG
Shield Shield G
All dataloggers apart from the CR3000 and CR5000 require the 4WPB100
module to interface the PT-100 to the datalogger. Table 4.3-3 shows the
wiring connections for the 4WPB100 (note this is using cable 2).
TABLE 4.3-3. Pt-100 Temperature Sensor Connections to 4WPB100 and Datalogger
Wire Label Color (Cable 2) 4WPB100 Datalogger
Black Wire Voltage Excitation (VX)
H Differential Input (H)
Current Excite Red L Differential Input (L)
Current Return Blue G (AG CR10X)
PT100 Signal White Differential Input (H)
PT100 Signal Ref Green Differential Input (L)
