NR01 Four-Component Net Radiation Sensor
5.2 Example Programs
5.2.1 Example 1, CR1000 Using Differential Channels
Program Example 1 requires six differential channels and the 4WPB100
module to measure the four radiation outputs and the Pt-100 temperature
sensor, connected on differential channels 1..6. The program measures the
sensors every two seconds, then calculates and stores the following data to
final storage every 60 minutes:
Year
Julian
Day
Hour/Minute
Avg SR01 Up (short wave radiation)
Avg SR01 Down (short wave radiation)
Avg IR01 Up (long wave radiation)
Avg IR01 Down (long wave radiation)
Avg NR01 temperature (degrees C)
Avg NR01 temperature (degrees K)
Avg Net shortwave radiation
Avg Net long wave radiation
Avg Albedo
Avg Total Net radiation
Avg temperature corrected IR01 Up
Avg temperature corrected IR01 Down
Wiring for Program Example 1
Color Function
Example CR1000
Program
Channels Used
Red SR01 Up Signal 1H
*Blue SR01 Up Reference 1L
White SR01 Down Signal 2H
*Green SR01 Down Reference 2L
Brown IR01 Up Signal 3H
*Yellow IR01 Up Reference 3L
Purple IR01 Down Signal 4H
*Grey IR01 Down Reference 4L
Shield Shield
*Jumper to with user supplied wire.
