9522B Iridium Satellite Modem and COM9522B Interface Modem
TABLE 1-2. Remote Station COM9522B Wiring
Hardware ComPort Description Color Connection
9522B
Antenna
“ANT” SMA connector to antenna cable
using 18436 adaptor
COM9522B Interface 26-pin ribbon cable connector
COM9522B
Power Control Yellow Control Port Datalogger (5V power trigger)
Ground Black
G (Datalogger / Direct to Station Power
Supply)
Modem Power Red
12V (Datalogger / Direct to Station Power
Supply)
18663 RS-232
Serial
Communications
18663 9-pin connector of COM9522B
SC932A
(optional)
CS I/O
“DCE Device” 10873 9-pin connector of COM9522B
“Datalogger” SC12 CS I/O port of Datalogger
TABLE 1-3. Base Station COM9522B Wiring
Hardware ComPort Description Color Connection
9522B
Antenna
“ANT” SMA
connector to
antenna cable
COM9522B Interface
26-pin ribbon cable
connector
COM9522B
Power Control Yellow
12V (Direct to
Station Power
Supply)
Ground Black
G (Direct to Station
Power Supply)
Modem Power Red
12V (Direct to
Station Power
Supply)
10873 RS-232
Serial
Communications
10873 Connect to PC
1.4 Power Control
The COM9522B will be used to control power to the modem with the use of
5 Vdc trigger on a datalogger control port (ex. C1: yellow wire). It is possible
to power the modem from the datalogger; however, it is recommended that a
separate power source be used for the modem to avoid catastrophic loss of data
in case of power failure. The COM9522B must draw power directly from a
12 Vdc power supply (power +: Red, ground/power –: Black).
