9522B Iridium Satellite Modem and COM9522B Interface Modem
TABLE 1-1. Equipment List for Base and Remote Stations
Base Station Remote Station
30693 9522B L-Band Data Modem
30693 9522B L-Band Data Modem
30627 Mounting Kit
30741 Antenna 30741 Antenna
18017-L Antenna Cable 18017-L Antenna Cable
18436 Right Angle SMA Adaptor
(may be required depending on
installation)
18436 Right Angle SMA Adaptor
30653 COM9522B 30653 COM9522B
Iridium SIM Card (comes with
modem)
Iridium SIM Card (comes with
modem)
10873 serial cable (used to connect
PC to the COM9522B)
18663 Null Modem Cable (1 ft lead)
OR
SC932A with 10873 and SC12 (only
required if using CSI/O port of
datalogger)
OR
SC110 9-pin Male DTE to Bare
Leads (only required if using a
datalogger COM Port)
30626 Mounting Kit for 30741
Antenna
30626 Mounting Kit for 30741
Antenna
The Iridium Satellite Modem and Interface Kit (pn 30694) includes most items
shown above for a base or remote station. It does not include the 18017-L
Antenna Cable which must be ordered at the desired length. Also, it includes
only the default option (18663 Null Modem Cable) for connecting the remote
station to a datalogger.
1.3 Hardware Overview
TABLE 1-1 lists the hardware typically used for both a base and remote
station. TABLE 1-2 and TABLE 1-3 list common wiring for both the remote
and base stations. FIGURE 1-1 to FIGURE 1-3 represent the typical
configurations of the base and remote stations. Please refer to Appendix B,
Hardware Installation, for a thorough description of the installation procedure
for both the base and remote stations.
Be sure that the 30741 antenna is connected to either of
the modems before applying power, as damage to the
equipment may occur.
WARNING
2
