Flytec
Allgemein: Sollte es nicht heissen “speed indicator” statt “speedometer” ??
Ebenfalls: “km/h” statt “km/h” (beide kommen vor!)
1
Introduction
Connection to a GPS navigation receiver
Setting a GPS NMEA 183 interface
(Korrektur im englischen Text: NMEA statt “NEMA” auf Seite 18)
4
3.
Glide ratio display
8. Speed sensor Socket
9. PC, printer and GPS interface
5
..... the relevant function key for approximately 3 seconds.
6
..... and option modes as well as additional configurations can .....
11
You can enter the vario’s setting mode by holding down the $$ key (for approximately 3
seconds).
This automatically activates the final approach computer (on) or, if pressed again, deactiva-
tes it (off). The preset wind component is shown in the SPEED display for the purpose of
information.
13/14
Descent alarm and polar input setting mode
Descent alarm and polar input option mode
Four polars can be defined and saved .....
Activating the polars
Press the $$ key to activate one of the four polars. The polar number is displayed in the
upper digital vario window. The polar selected remains activated after exiting OPTION mode.
Polar input
After selecting the polar, the relevant supporting values can be entered manually. Pressing
the $$ key starts polar input at 20 km/h. The current horizontal speed is shown in the SPEED
display. The flashing display shows the corresponding descent value. The value can be ente-
red in steps of 0.1 m/s with the $$ and $$ keys. Pressing the $$ key again increases the
