Transmission to a PC
The flights recorded can be transmitted to a PC. You will require a PC with Windows 3.X or
Windows® 95, a PC cable and Flytec’s software.
Transmission is started from the PC Software FlyChart. It is required that the instrument is in
the run mode on the MEMO display (fligth 0). The entire flight memory is then transmitted to
the PC where the flights can be saved and printed out.
The PC software can be used to print
out a colour graphic of the barogram VARIO, SPEED and TEMP data.
Barograph setting mode
In setting mode, all flights in the logbook can be
deleted and the recording interval of the barograph
can be set.
In setting mode, the recording interval saved is dis-
played first. Using the key or the key, chan-
ge in the MEMO display between the recording
intervals 1, 5, 15 sec and CI. Briefly press MEMO
to save the interval displayed and thus leave set-
ting mode.
If Cl appears in the MEMO display, all the flights
can be deleted by pressing the key for 4
seconds. As soon as the memory has been dele-
ted, all the segments of the display will flash brief-
ly and the instrument starts up again.
Barograph option mode
The magnitudes which the barograph is to record
are set at the first level of option mode.
Use the key or the key to toggle between
the different possibilities. The magnitudes to be
recorded flash in the display:
• ALT 1 and SPEED Altitude and speed
• m/s ft/min x 100 and SPEED Ascent and speed
• ALT 1 and TEMP Altitude and temperature
• ALT 1 Altitude only
The printer emulation must be given at the
second level of the OPTION mode:
EP
Ł
Epson FX-80
Ibm
Ł
IBM Proprinter
HP
Ł
HP Deskjet
Flytec
Operating Instructions FLYTEC 4030 28
SET-MODE
• Intervalle des enreg.
1, 5, 15 sec.
• Clear Barographe
(ALT 4 sec.)
OPTION-MODE
Recording
• ALT1 & SPEED
• Vario & SPEED
• ALT1 & TEMP
• only ALT1
Printer emulation
Epson - IBM - HP
Printout width
Norm - Cond
Name
21 Characters
MEMO
MEMO
MEMO 4 Sec.
OPTION
MEMO
MEMO
MEMO
OPTION
➀
➁
➂
➃
START - STOP
RESET
CLEAR ALT 2
ALT 1
ALT 2
CHRONO
START - STOP
RESET
CLEAR ALT 2
