Sample printout:
Barograph
Recording
Recording is done with the REC switched on. The saving rate is adjustable (1, 5 or 15 sec), as
well as the magnitudes to be saved.
(Cf. OPTION mode MEMO). The accuracy of the 4 magni-
tudes is: altitude = 1m, SPEED = 1 km/h, VARIO = 0.1 m/s, TEMP = 1°C. With altitude recording
at 15-second saving rate, the maximum saving time is > 50 hours. (Larger memory available on
request).
Switching off the REC switch stops the barograph recording process and saves the flight
in memory. If the REC switch is not switched off, the current recording is saved when the instru-
ment is switched off.
IMPORTANT: If the REC switch is not activated, there will be no barograph recording; conse-
quently, only the flying time and the peak values will be saved when the instrument is switched
off.
Time marker
While a flight is being recorded you can set time markers in the barogram durging the flight. For
example, the turning-point can be recorded in the barogram. These markers are plotted in the
printout and displayed in the FlyChart software. While a flight is being recorded you can set time
markers by pressing the key (the indicator must be on ALT1 or CHRONO) until a number
appears briefly in the upper display. This is the number of the markers that have been set.
Printout
The barogram can be printed out directly on any EPSON-, IBM- or HP-compatible printer. (For
printer selection, please refer to OPTION mode MEMO). Either a parallel (Centronics) or a seri-
al (RS232) cable (special accessory) is required according to the type of printer used.
Switch the instrument to MEMO mode with the key. Select the flight you require from the log-
book list by pressing the key and the key. NB: you can only print out flights which have an
ALT mark in the barogram column. No VARIO, SPEED or TEMP recordings are printed out in a
direct printout. Start a printout by holding down the key in the MEMO mode display (REC
switch must be switched off). The altitude scale is automatically adjusted (2,400, 4,800 or
9,600m) in the printout.
Flytec
Operating Instructions FLYTEC 4030 27
DATE TIME ALTI1 ALTI2 VARIOMETER REC Barogram Sample
Nr.dd.mm.yy hh:mm MAX MAX MAX MIN TIME TIME
1. 03.01.95 11:23 2032 204 1.2 -14.6 00:33 ALT TEMP 15
2. 05.01.95 13:45 1892 349 2.5 -12.3 01:26 ALT SPEED 15
3. 12.02.95 12:03 1580 89 0.8 -9.8 00:23 NO -
4. 03.01.95 11:23 2032 204 1.2 -2.0 01:09 ALT 15
Nr.dd.mm.yy hh:mm [m] [m] [m/s] [m/s] hh:mm [sec]
ALT 1
ALT 2
CHRONO
TIME
SPEED
MEMO
START - STOP
RESET
CLEAR ALT 2
PRINT
