Vario and Polar
Vario sound levels
Two sound levels can be set or the sound system switched off completely by repeatedly
pressing the key. While the key is pressed, a tone will sound at the desired level.
Analog vario bar display
The vario bar display has a range of ± 8 m/s in two scale passes. The scale unit always cor-
responds to 0.2 m/s. Up to 4 m/s , the bar display fills. If it displays more than 4 m/s (ascent),
the ascent is displayed inverted, i.e. the display is full at 4 m/s and empties from below when
ascent increases.
E.g.:
The sensitivity of the bar display corresponds to the basic attenuation of the vario (‡ setting
mode of the vario). It therefore always displays current ascent.
Digital vario display (Integrator)
The digital vario displays the attenuated climb rate for the last X seconds in second rate. The
time X, via which ascent is attenuated (integration time), can be changed at the first level of
option mode. These values appear flashing in the digital vario display.
Flytec
Operating Instructions FLYTEC 4030 11
0-I-II 0-I-II
➞
➞
1.6 m/s 4 m/s 5 m/s
