38 DSR Installer/User Guide
4. Type the number of minutes for Inactivity Time (from 1–99) to delay
activation of the screen saver.
5. Choose Energy if your monitor is E NERGY S TAR compliant; otherwise
select Screen.
CAUTION: Monitor damage can result from the use of Energy Mode with monitors not compliant
with E
NERGY S TAR
® .
6. (Optional) Click Test to activate the screen saver test which lasts 10
seconds then returns you to the Security dialog box.
7. Click OK.
NOTE: Activation of the screen saver mode disconnects the user from a server; no server is
selected. The status fl ag displays Free.
To exit the screen saver mode:
Press any key or move your mouse. Any previous server connection will
be restored.
To turn off the screen saver:
1. From the Main dialog box, click Setup - Security. The Security dialog box
will appear.
2. In the Security dialog box, clear Enable Screen Saver.
3. Click OK.
To immediately turn on the screen saver:
Press Print Screen, then press Pause. This command only works when the
user is connected to a server.
Setting the Keyboard Country Code
NOTE: Using a keyboard code that supports a language different from that of your DSR switch
fi rmware will cause incorrect keyboard mapping.
Sun servers may use key mappings for non-US keyboards. By default, the
DSR1021 switch sends the US keyboard country code to Sun and USB modules
attached to servers, and the code is applied to the servers when they are
powered up or rebooted. Codes are then stored in the DSRIQ module.
Issues may arise when you use the US keyboard country code with a keyboard
of another country. For example, the Z key on a US keyboard is in the same
location as the Y key on a German keyboard. Sun servers will interpret
pressing the Y key on a German keyboard as pressing the Z key when the US
keyboard country code is used.
