Avocent DSRTM 1021 - Manual (Page 36)

Chapter 3: Local Port Operation 33
To turn broadcasting off:
From the Commands dialog box, clear the Broadcast Enable checkbox.
Using Scan Mode
In scan mode, the DSR1021 switch automatically scans from port to port
(server to server). You can scan up to eight servers, specifying which servers
to scan and the number of seconds that each server will display. The scanning
order is determined by placement of the server in the list. The list is always
shown in scanning order. You can, however, choose to display the server’s
name or EID number by pressing the appropriate button.
NOTE: Scanning is only available to the local user.
To add servers to the scan list:
1. If the OSCAR interface is not open, press Print Screen. The Main dialog
box will appear.
2. Click Setup - Scan. The Scan dialog box appears.
Figure 3.9: Scan Dialog Box
3. Determine the order within the list to add the server. If there are no servers
in the scan list, your cursor will appear in a blank line at the top of the list.
-or-
To add a server to the end of the list, place your cursor in the last server
entry and press the Down Arrow key.
-or-
