24 DSR Installer/User Guide
OSCAR Interface Navigation Basics (continued)
This Keystroke Does This
Escape Closes the current dialog box without saving changes and
returns to the previous one. If the Main dialog box is displayed,
pressing Escape closes the OSCAR interface and displays a
status fl ag if status fl ags are enabled. See Controlling the
Status Flag in this chapter for more information. In a message
box, it closes the pop-up box and returns to the current
dialog box.
Alt Opens dialog boxes, selects or checks options and executes
actions when used with underlined or other designated letters.
Alt+X Closes the current dialog box and returns to the previous one.
Alt+O Selects the OK button, then returns to the previous dialog box.
Enter Completes a switch operation in the Main dialog box and
exits the OSCAR interface.
Single-click, Enter In a text box, it selects the text for editing and enables the Left
and Right Arrow keys to move the cursor. Press Enter again
to quit the edit mode.
Print Screen, Backspace Toggles back to previous selection.
Print Screen, Alt+Ø Immediately disengages user from a server; no server is
selected. Status fl ag displays Free. (This only applies to the Ø
on the keyboard and not the keypad.)
Print Screen, Pause Immediately turns on screen saver mode and prevents access to
that specifi c console, if it is password protected.
Up/Down Arrows Moves the cursor from line to line in lists.
Right/Left Arrows Moves the cursor between columns. When editing a text box,
these keys move the cursor within the column.
Page Up/Page Down Pages up and down through Help pages.
Home/End Moves the cursor to the top or bottom of a list.
Backspace Erases characters in a text box.
Delete Deletes current selection in the scan list or characters in a
text box.
Shift-Del Deletes from the current selection to the end of the list when
editing a scan list.
Numbers Type from the keyboard or keypad.
