MICRSafe with 3-Track MSR
50
The nonnumeric CMC-7 characters are translated by the MICRSafe as shown in Table B-1.
Table B-1. CMC-7 Nonnumeric Characters
CMC-7 Character MICRSafe Output
SI A
SII B
SIII C
SIV D
SV E
CHECK LAYOUTS
Personal checks with MICR fields are shown in Figure B-1. Business checks are shown in
Figure B-2. The digits 1 through 4 in the illustrations are described below under MICR Fields.
Figure B-1. Personal Checks
2.75”
6.00”
1 2 3
