1 T/C lead is WHITE and negative (-) constantan (non-magnetic).

WIRING INFORMATION

Square Coil heaters are supplied with 2" prestripped 42" long leads.
Heaters are 240 VAC (120 VAC square coil heaters are available on request).
2 power leads are MULTI COLOR
1 ground lead is GREEN.
Thermocouples are "J" Type.
Thermocouples are supplied with 40" leads.

1 T/C lead is BLACK and positive (+) iron (magnetic).

J INCL

80°

INCL

B

0.0000

+0.0005

DIA.

K RAD.

0.005 LAND (MAX.)

0.030

TO SUIT

M MIN.

0.187 SPH. RAD.

0.140

0.125 RAD.

0.625 WIRE CHANNEL

E DIA.

B

0.0000

+0.0060

C DIA.

0.000

+0.002

H

0.31 MIN. DISTANCE BETWEEN WATERLINE

AND DROP

30°

"A" + BE

SEE NOTE

D DIA.

4.000 DIA.

0.219 MIN.

W

0.125 RAD.

3.90

7/32

4" DIA.

LENGTH

5/16-18 TAPPED

* ON A 1-21/32 CIRCLE RADIUS, AND 45

DRILLED & C'BORED FOR

THRU 2 PLACES *

5/16-18 S.H.C.S. (2) *

GATE MATE LOCATING RINGS

FROM CENTERLINE.

INSTALLATION DATA

ME-0739-PS-050-D

09-08

GMB9996

GATE-MATE BUSHING ASSEMBLIES

Please read carefully before installing components.

DANGER

WARNING

out residual moisture before applying full power. Failure to do so may cause

IMPORTANT SAFETY INFORMATION

A hot-runner system includes electrical elements and may contain molten
plastic at elevated temperature and pressure. To avoid injury, exercise
caution by reading these instructions before servicing or operating the
system.
These instructions must be passed on to the end user where they should
be read before using this product. Failure to do so can result in serious
injury or death.

Failure to comply can result in serious injury or death:
STORED ENERGY AND HIGH TEMPERATURE HAZARDS
This product maintains molten plastic at high pressure. Use caution when
operating and servicing the system.
Physical contact with molten plastic may result in severe burns. Proper
protective equipment, including eye protection, must be worn. This product
has heated surfaces. Use caution when operating and servicing the system
to avoid severe burns. Proper protective equipment should be worn.

Failure to comply will result in serious injury or death:
ELECTRICAL HAZARDS
Improper voltages or grounding can result in electrical shock. Use only
with proper voltage and a proper earth ground.
To avoid electrical shock, do not operate product when wet.
Do not operate this equipment with covers or panels removed.
To avoid electrical shock, turn off main power disconnect and lockout /
tag out before servicing this device. Do not connect temperature sensors to
electrical power. It will damage the product and it can cause fire, severe
injuries or even death.
If green ground wire present wire must be connected to the ground.
Do not rebend rigid leads. Rebending leads might result in damage to circuit.
Product might absorb moisture when cool. Use low Voltage or power to drive

damage to this product.

CANADA 800-387-6600

29111 STEPHENSON HIGHWAY
MADISON HEIGHTS
MICHIGAN 48071 USA

US 800-656-6656

www.dme.net

D-M-E COMPANY

Note: Dimensions shown in Inches.

0.375

2.375

GMB-523-2

0.563

0.44

GMB0007

factor. In some instances it may be necessary to obtain an empirical factor.

LENGTH

MEDIUM AND JUMBO GATE-MATE MACHINING DIMENSIONS

Please note that the above information is given as an example. Variations may occur based on mold configuration and cooling

GATE MACHINING DIMENSIONS

USED WITH

CATALOG NUMBER

1-1/2

2.187

2.157

GMB0008 & GMB0009

0.7500

3.375

GMB-533-2

90

0.875

1.625

F.

BE= 2.500 x 0.00000633 x (500 - 68) = 0.0068.... thus "A" + BE will be 2.5068.

(2) 5/16-18 S.H.C.S. ARE INCLUDED WITH LOCATING RINGS

1-25/32

GMB-523-2 & GMB-533-2

6545

NOTE: The expansion factor must be taken into consideration prior to machining for, and installing nozzle. This factor (BE) must
then be addeed to the nominal "A" dimension. Formula for determining this expansion is as follows:
