Avaya S8300 - Manual (Page 511)

Install New Firmware on the G700
Issue 9.1 June 2006 511
4. At the MG-???-1(configure)# prompt, type
copy tftp mgp-image
to transfer the mgp image from the tftp server to the G700,
where
is the bank that is not Active Now (Bank A in the example).
is the full path name of the mgp firmware image file, which begins with mgp
and will be similar to the name mgp_8_0.bin.
is the IP address of the S8300.
For example:
copy tftp mgp-image
a mgp_8_0.bin 195.123.49.54
The screen shows the progress.
5. Type set mgp bootimage
where is the same letter you entered in the previous step.
6. At the MG-???-1(configure)# prompt, type reset mgp.
A system prompt asks you to confirm the reset.
7. Select Yes at the dialog box that asks if you want to continue.
The G700 media gateway processor resets. The LEDs on the G700 media gateway and the
media modules flash. These elements each conduct a series of self-tests. When the LEDs
on the media modules are extinguished and the active status LEDs on the G700 media
gateway are on, the reset is complete.
8. When the P330-1(super)# prompt appears, type session mgp.
9. At the MGP-???-1(super)# prompt, type configure.
10. Verify that the download was successful when the prompt returns.
Type show mg list_config.
The system displays the list of software.
Example: Show mg list_config
SLOT TYPE CODE SUFFIX HW VINTAGE FW VINTAGE VOIP FW
---- ------ ----- ------ ---------- ---------- -------
V0 G700 DAF1 A 00 230(A) 67
V1 ICC S8300 A 72 00 N/A
V2 DCP MM712 A 2 58 N/A
V3 ANA MM711 A 2 57 N/A
V4 DS1 MM710 A 1 58 N/A
