Please read carefully before installing components.
INTERLOCKS
FOR BLACK &GOLD METRIC SIDE INTERCHANGEABLE
INSTALLATION DATA
02-10 Catalog # BGMSIP ME-06-0005-00011(A)
NOTE: Dimensions are in mm.
C A T # C A T # WP B M B F C D E R F / R M R T L
M A LE FEM A LE M A LE FEM A LE P OCKET P OCKET THREA D
P OCKET P OCKET P OCKET P OCKET RA DIUS RA DIUS SCREW LENGTH
LENGTH WIDTH WIDTH DEP TH SIZE M IN
+0.02
+0.01
+0.02
+0.01
+0.02
+0.01
+0.02
+0.01
+0
-0.5
+/-0.1
B GS05016M B GS05016F 50.00 21.50 21.50 16.00 11.00 17.00 5.0 0.2 M 6x20 Lg 12.0
B GS07519M B GS07519F 75.00 36.00 36.00 19.00 18.00 25.00 5.0 0.5 M 10 x 25 Lg 18.0
B GS10019M B GS10019F 100.00 45.00 45.00 19.00 22.00 35.00 5.0 0.5 M 10 x 25 Lg 18.0
B GS12525M B GS12525F 125.00 45.00 45.00 25.00 22.00 42.00 5.0 1.0 M 10 x 30 Lg 17.0
SCREWS
LOCA TIONS
+/-0.2
Installation Instructions:
1. Four D-M-E Side Interlocks must be used in each mold application. When in operation,
the interlocks contact the edges of the machined pocket to maintain Parting line alignment.
The cap screws are only utilized to retain the interlocks to the mold base.
2. To maintain alignment, it is recommended that the mold base assembly be clamped
together and machined in assembly to insure proper parting line alignment.
3. Machine the interlock pockets accurately in assembly. Locate each interlock pocket on the
centerline of the mold. The location is critical to avoid misalignment problems which
could result from uneven thermal expansion of the separate mold halves.
4. Mount the female interlock on the half of which will have the highest operating
temperature. Normally, this will be the “A” side of the mold. This procedure is critical to
insure that the male interlock does not grow larger than the female interlock if uneven
mold temperatures are present.
5. Place both male and female interlocks into the pockets while the mold is clamped together
then thread in and tighten screws.
6. Torque the mounting SHCS to:
x 27 N x m [19.8 FT x LBS] for M6-1.0 SHCS
x 130 N x m [95.5 FT x LBS]for M10-1.5 SHCS
7. After installation, open and close the mold on the bench to insure proper alignment.
8. For “shuttle” molds repeat steps 2 to 7 for each interchangeable “B” side.
