VK-2 Universal Keyboard
VK-2 Universal Keyboard User Manual
14
3 Dome Protocols
3.1 Current Protocol Support
A VK-2 is capable of controlling a mixture of two different types of dome. All domes of one type must be
connected to the “
DOMES-1” output, and all domes of the other type must be connected to the “DOMES-
2” output. These outputs must each be allocated one of the following protocol numbers (See sections 1.5.3
and 1.5.4):
Note that some domes support protocols from other manufacturers, or may be controlled via a protocol
converter. It is important to select the correct protocol from the list below, not necessarily the manufacturer
of the dome.
Protocol
Number
Protocol Output Used Comments
1 Slave RS485 Select this protocol in all slave VK2’s.
2 JVC RS485 Direct connection via twisted pair.
3 Molynx RS485 Connect directly to Molynx receivers via twisted pair.
4 Dennard RS485 Direct connection via twisted pair.
5 VCL RS485 Direct connection via twisted pair.
6 Sanyo RS485 Direct connection via twisted pair.
7 BBV RS232 Connect to a BBV transmitter such as the TX1000/8,
which provides control of BBV compatible domes &
receivers via coax.
8 BBV 20mA Connection to BBV compatible receivers via twisted
pair. The RX100 receivers provide coax or RS485
control of a range of dome domes as supported by
BBV.
9 Forward Vision (VCL) RS485 Direct connection via twisted pair. Note that the dome
must be purchased with the VCL-based protocol
option.
10 Mercer RS485 Direct connection via twisted pair.
11 Merit Lilin RS485 Direct connection via twisted pair.
12 Borsatec RS485 Direct connection via twisted pair.
13 Samsung RS485 Direct connection via twisted pair.
14 Pelco-D RS485 Direct connection via twisted pair.
