Vi-R4000 Series
Videoswitch Page 2 Mdr602a.doc
1.1 Monitors
The DVR can provide the follow output screens:
• Main This is used for full-screen or multi-screen live, play and configuration
• Aux
This is used for full-screen or multi-screen live and play
• Spot Spot monitors are used for live full-screen viewing
These output screens are displayed on the monitors with a priority depending on what types of monitor
are connected:
HDMI VGA BNC x4 Main Aux Spot
- Connected Optional VGA BNC BNC x3
Connected - Optional HDMI BNC BNC x3
Connected Connected Optional HDMI BNC BNC x4
- - Yes BNC n/a BNC x3
Note that the HDMI and VGA monitors VGA Monitor must be connected prior to power-up so that they
are detected and given the correct usage.
1.1.1 VGA Monitor
A VGA monitor is recommended for most application for ease of interface and to benefit from high
resolution images. Supported resolutions are: 1920Ч1080, 1600Ч1200, 1280Ч1024, 1280Ч720 and
1024×768. The Vi-R4000 series allows units to be cascaded and to share a common VGA monitor
(and mouse). Refer to section 0.
1.1.2 HDMI / DVI Monitor
A HDMI or DVI Monitor may also be connected and is especially useful when used in conjunction with
a VGA monitor to provide dual independent high-resolution displays. Supported resolutions are:
1920Ч1080, 1600Ч1200, 1280Ч1024, 1280Ч720 and 1024×768.Note that a HDMI to DVI cable is
required to use a monitor with a DVI port.
1.1.3 BNC Monitors
Four BNC monitor outputs are provided which may be used for Main, Aux and Spot displays.
