3.2 Default Configuration
3.2.1 System Configuration
The DVR is delivered with the system configuration already defaulted.
These settings ensure that it will record and play cameras once correctly connected up. The
configuration settings may be adjusted in the menu to suit the particular installation.
To revert to the default Videoswitch configuration, go to this menu:
Menu >System Maintenance > Import/Export
You can now import the default configuration from the supplied memory stick (using the USB port in
the front panel beside the DVD drive).
The default configuration file is also available on our website:
www.videoswitch.co.uk Firmware Updates
Note : The firmware must match that of the configuration file. If you upgrade the DVR firmware you will
need to export the configuration again if you wish to retain a copy of the settings for future use.
3.2.2 Interface Configuration
The DVR is delivered with the Interface configuration already defaulted.
There are a number of settings relating to the cameras and multi-unit operation that are set by means
of simple 4 digit codes. To prevent accidental operation, the LIVE key must be pressed and held while
these codes are entered. Further protection is provided by a locking facility, using a command to lock
and another command to unlock access to the other functions:
3.2.2.1 Unlock Interface Settings
The interface system is locked on power up. It must be unlocked before any other settings can be
changed. When unlocked, the power LED on the front panel will be OFF.
Press and hold LIVE key, enter 9001, release LIVE key
3.2.2.2 Lock Interface Settings
If you have made changes and wish to lock the Interface settings, apply this command:
Press and hold LIVE key, enter 9000, release LIVE key
Note: if no commands are issued for a minute, the interface will automatically lock. When locked, the
power LED on the front panel will be ON.
3.2.2.3 Display Interface Firmware Revision
The revision of the Interface Controller can be displayed on the power LED by entering this command:
Press and hold LIVE key, enter 9002, release LIVE key
The LED stays on for a few seconds then displays three groups of flashes, encoding a 3-digit revision
number. The sequence is repeated until cancelled.
3.2.2.4 Default all Interface Settings
All Interface setting scan be defaulted by issuing this command:
Press and hold LIVE key, enter 9999, release LIVE key
