3.5 Casacading
3.5.1 Vi-R4000 Recorders (address range 2)
If multiple Vi-R4000 series Recorders are cascaded (see connection details in section 2.2.3) no
address configuration is required. The DVRs by default have an an address range of 2 so addresses
will be assigned automatically as follows:
DVR
Unit Address
Analogue
Cameras
Network Cameras
1
1 & 2
1 - 16
17 - 32
2
3 & 4
33 - 48
49 - 64
3
5 & 6
65 – 80
81 – 96
4
7 & 8
97 – 112
113 – 128
5
9 & 10
129 – 144
145 – 160
6
11 & 12
161 – 176
177 – 192
7
13 & 14
193 – 208
209 - 224
8
15 & 16
225 – 240
241 - 256
