CDN TA20 - Audio/Visual Refrigerator/Freezer Alarm EN - Manual

Perfect For
• Maintaining food-safe temperatures
in refrigerators or freezers
Easy To Use
• Dual progress display
• Audio/visual alert
Features
• Shatterproof
• 39"/1 m sensor cable
• ABS plastic
• Sliding mode switches: F/C; refrigerator/freezer;
alert on/off
• Temperature guide
• Velcro ® tabs secure case to outside surface
• Suction cup firmly attaches sensor to inside surface
• Battery and instructions included
Note: Remove sticker from display before use.
Note: In the following instructions, names of the control
buttons are shown in CAPS. Function information that appears
on the display is shown in BOLD CAPS.
Battery Installation
Battery is installed. Replace battery when LCD
becomes dim or alert level declines.
1. Open battery door in back by sliding in direction
of arrow and lift.
2. Install 1.5V AAA battery observing polarity shown
in compartment.
3. Close battery door and push in opposite direction
of arrow to lock.
Operating Instructions
1. Place the probe sensor well inside the refrigerator
or freezer in a central location by pressing suction
cup firmly against inside surface.
2. Remove the protective papers from one side of
each of the Velcro ® tab pairs and adhere complete
pairs to rectangular areas on back of case.
3. Determine where the case will be mounted to
the outside surface. Wipe the surface area clean,
remove the protective papers from opposite sides
of Velcro ® tab pairs, and adhere tabs to surface by
pressing firmly. Wait 15 minutes for adhesive to set
before removing case.
4. Select Fahrenheit or Celsius using sliding mode
switch on side of case.
5. Select Refrigerator or Freezer using sliding mode
switch to the far left of the display.
6. Select audio/visual alert by sliding mode switch
to the immediate left of the display to the ON
position. ALERT appears on Refrigerator/Freezer
side of the dual display when audio/visual alert
is ON.
7. Alert sounds and LED lights flash for 5 seconds
every minute when the internal temperature rises
above the safety zone.
Care of Your Product
• Avoid exposing your thermometer to extreme
temperatures, water or severe shock.
• Avoid contact with any corrosive materials such as
perfume, alcohol or cleaning agent.
• Wipe display clean with a damp cloth.
Model: TA20
Audio/Visual
Refrigerator/Freezer Alarm
Signal sounds at 15° or 46°F/-9.5° or 8°C
Suction cup firmly attaches
sensor to inside surface
Built-in sensor
ALERT appears when
audio/visual alert is ON
Probe sensor
Double-sided Velcro ® tabs
for easy outside mounting
