Page 2-30 Rev. 0040807015 1014
Operating Instructions
ARImetec
®
-S
7.1.1 Steam table
Overpressure
Absolute
pressure Boiling
temperature
Body /
surface
temperature
Overpressure
Absolute
pressure Boiling
temperature
Body /
surface
temperature
p p t
S
t
external
p p t
S
t
external
bar(ü) bar °C °C bar(ü) bar °C °C
-0.99 0.01 6.92 6.29 17 18 207.1 188.27
-0.98 0.02 17.51 15.91 19 20 212.4 193.09
-0.97 0.03 24.1 21.90 23 24 221.8 201.63
-0.95 0.05 33 30 27 28 230 209.09
-0.92 0.08 41.5 37.72 29 30 234 212.72
-0.9 0.1 45.8 41.63 33 34 241 219.09
-0.8 0.2 60.1 54.63 37 38 247.3 224.81
-0.6 0.4 76 69.09 39 40 250.3 227.54
-0.4 0.6 86 78.18 44 45 257.4 234
-0.2 0.8 93.5 85 49 50 264 240
0 1 99.6 90.54 54 55 270 245.45
0.2 1.2 104.8 95.27 59 60 275.6 250.54
0.4 1.4 109.3 99.36 64 65 281 255.45
0.6 1.6 113.3 103 69 70 286 260
0.8 1.8 117 106.36 74 75 290.5 264.09
1 2 120.2 109.27 79 80 295 268.18
1.4 2.4 126.1 114.63 84 85 299.2 272
1.8 2.8 131.2 119.27 89 90 303.3 275.72
2 3 133.5 121.36 94 95 307.2 279.27
2.4 3.4 138 125.45 99 100 311 282.72
2.8 3.8 141.8 128.90 109 110 318 289.09
3 4 143.6 130.54 119 120 325 295.45
3.5 4.5 148 134.54 129 130 331 300.90
4 5 151.8 138 139 140 336.6 306
5 6 158.8 144.36 149 150 342 310.90
7 8 170.4 154.90 159 160 347.3 315.72
9 10 180 163.63 179 180 357 324.54
11 12 188 170.90 199 200 365.7 332.45
13 14 195 177.27 220.3 221.3 374.15 340.134
15 16 201.4 183.09
