Red Lion ZNH - FLANGE MOUNT - Manual (Page 2)

MODEL NO. PPR
2.5" Flange
Mount
PART NUMBER
2" Flange Mount
ZDH
&
ZNH
Rotary Pulse Generators
1000
60
ZNH1000H
ZNH0060H
ZDH1000H
ZDH0060H
1200
100
ZNH1200H
ZNH0100H
ZDH1200H
ZDH0100H
2500
600
2000
500
ZNH2500H
ZNH0600H
ZDH2500H
ZDH0600H
ZNH2000H
ZNH0500H
ZDH2000H
ZDH0500H
DESCRIPTION
ORDERING INFORMATION
ACCESSORIES
MODEL NO. DESCRIPTION PART NUMBER
CCBRPG
7-Pin MS Connector CCBRPG00
7-Pin MS Connector w/10 ft 24 AWG 5
Conductor w/drain
CCBRPG02
7-Pin MS Connector w/20 ft 24 AWG 5
Conductor w/drain
CCBRPG03
RPGFC
Flexible Coupling (1" Length) 0.25" - 0.375" RPGFC002
Flexible Coupling (1" Length) 0.375" - 0.375" RPGFC003
Flexible Coupling (1.5" Length) 0.375" - 0.5" RPGFC004
Flexible Coupling (1" Length) 0.375" - 6 mm RPGFC006
Note: Only Factory Stocked part numbers are listed. Consult Factory for part
number and availability of other PPR and Output Configurations.
LIMITED WARRANTY
The Company warrants the products it manufactures against defects in materials and
workmanship for a period limited to two years from the date of shipment, provided the products
have been stored, handled, installed, and used under proper conditions. The Company’s liability
under this limited warranty shall extend only to the repair or replacement of a defective product,
at The Company’s option. The Company disclaims all liability for any affirmation, promise or
representation with respect to the products.
The customer agrees to hold Red Lion Controls harmless from, defend, and indemnify RLC
against damages, claims, and expenses arising out of subsequent sales of RLC products or
products containing components manufactured by RLC and based upon personal injuries, deaths,
property damage, lost profits, and other matters which Buyer, its employees, or sub-contractors
are or may be to any extent liable, including without limitation penalties imposed by the
Consumer Product Safety Act (P.L. 92-573) and liability imposed upon any person pursuant to
the Magnuson-Moss Warranty Act (P.L. 93-637), as now in effect or as amended hereafter.
No warranties expressed or implied are created with respect to The Company’s products except
those expressly contained herein. The Customer acknowledges the disclaimers and limitations
contained herein and relies on no other warranties or affirmations.
6. MOMENT OF INERTIA: 5.2 x 10 -4 oz-in-sec 2 (3.66 x 10 -3 N-mm-sec 2 )
7. CONNECTOR TYPE: 7-Pin MS type connector
8. HOUSING: Black non-corrosive finish
9. MOUNTING:
ZDH: 2.0" Flange Mount
ZNH: 2.5" Flange Mount
10. WEIGHT: 11 oz. (311.8 g)
ENVIRONMENTAL CONDITIONS
1. OPERATING TEMPERATURE: 0 to +70 °C
2. STORAGE TEMPERATURE: -25 to +85 °C
3. HUMIDITY: 98% RH non-condensing
4. SHOCK: 75 g @ 11 msec duration
5. SEALING: NEMA 4, 13 and IP66 with shaft seal
FUNCTION PIN WIRE COLOR
+VDC A RED
COMMON B BLACK
DATA A C WHITE
DATA B D GREEN
CASE GROUND
INDEX Z
F
E
BARE WIRE
ORANGE
