1. DISPLAY: 5 digit LCD 0.48" (12.2 mm) high digits
CUB5RTR0: Reflective LCD with full viewing angle
CUB5RTB0: Transmissive LCD with selectable red or green LED backlight,
viewing angle optimized. Display color change capability with output state
when using an output module.
2. POWER: Input voltage range is +9 to +28 VDC with short circuit and input
polarity protection. Must use an RLC model MLPS or a NEC Class 2 or
Limited Power Source (LPS) rated power supply.
3. READOUT:
Resolution: 1 or 0.1 degrees
Scale: °F or °C
Offset Range: -19999 to 19999 display units
4. RTD INPUTS:
Isolation: Input and EXC terminals are not electrically isolated from the
power supply or optional comms cards.
Failed Sensor Display:  or 
Overrange/Underrange Input: 
/
Overrange/Underrange Display : “
..... ”/“- ..... ”
Maximum Input Voltage: 30 VDC
Type: 2, 3 or 4 wire
Excitation current: 100 ohm range: 165 μA
10 ohm range: 2.5 mA
Lead resistance: 100 ohm range: 10 ohm/lead max.
10 ohm range: 3 ohms/lead max.
Balanced Lead Resistance: Automatically compensated up to max per lead.
Unbalanced Lead Resistance: Uncompensated.
*After 20 min. warm-up. Accuracy is specified in two ways: Accuracy at
23°C and 15 to 75% RH environment; and Accuracy over a -35 to 75°C and
0 to 85% RH (non condensing) environment. Accuracy specified over the -35
to 75°C operating range includes meter tempco effects. The specification
includes the A/D conversion errors and linearization conformity. Total system
accuracy is the sum of meter and probe errors. Accuracy may be improved by
field calibrating the meter readout at the temperature of interest.
5. RESPONSE TIME:
Display: 500 msec min.
Output: 1.25 sec max (with input filter setting of 0)
6. USER INPUT (USR): Programmable input. Connect terminal to common
(USR COMM) to activate function. Internal 10K  pull-up resistor to +9 to
28 VDC.
Threshold Levels: V
IL
= 0.7 V max; V
IH
= 2.4 V min; V
MAX
= 28 VDC
Response Time: 5 msec typ.; 50 msec debounce (activation and release)
7. CERTIFICATIONS AND COMPLIANCES:
CE Approved
EN 61326-1 Immunity to Industrial Locations
Emission CISPR 11 Class A
IEC/EN 61010-1
RoHS Compliant
UL Recognized Component: File #E179259
UL Listed: File #E137808
Type 4X Outdoor Enclosure rating (Face only)
IP65 Enclosure rating (Face only)
IP20 Enclosure rating (Rear of unit)
Refer to EMC Installation Guidelines for additional information.
8. MEMORY: Nonvolatile E 2 PROM memory retains all programming
parameters and max/min values when power is removed.
9. CONNECTIONS: Wire clamping screw terminals
Wire Strip Length: 0.3" (7.5 mm)
Wire Gage: 30-14 AWG copper wire
Torque: 5 inch-lbs (0.565 N-m) max.
10. ENVIRONMENTAL CONDITIONS:
Operating Temperature Range for CUB5RTR0: -35 to 75 °C
Operating Temperature Range for CUB5RTB0 depends on display color
and intensity level as per below:
INTENSITY LEVEL TEMPERATURE
Red Display 1 & 2 -35 to 75°C
3 -35 to 70°C
4 -35 to 60°C
5 -35 to 50°C
Green Display 1 & 2 -35 to 75°C
3 -35 to 65°C
4 -35 to 50°C
5 -35 to 35°C
Storage Temperature: -35 to 85 °C
Operating and Storage Humidity: 0 to 85% max. relative humidity (non-
condensing)
Vibration to IEC 68-2-6: Operational 5-500 Hz, 5 g
Shock to IEC 68-2-27: Operational 30 g
Altitude: Up to 2000 meters
11. CONSTRUCTION: This unit is rated for NEMA 4X/IP65 requirements for
outdoor use. Installation Category I, Pollution Degree 2. High impact plastic
case with clear viewing window. Panel gasket and mounting clip included.
12. WEIGHT: 3.2 oz (100 g)
2
G
ENERAL
M
ETER
S
PECIFICATIONS
O
RDERING
I
NFORMATION
MODEL
NO.
DISPLAY COLOR
INPUT CURRENT
@ 9 VDC WITHOUT
CUB5RLY0
INPUT CURRENT
@ 9 VDC WITH
CUB5RLY0
CUB5RTR0 --- 10 mA 40 mA
CUB5RTB0 Red (max intensity) 85 mA 115 mA
CUB5RTB0 Green (max intensity) 95 mA 125 mA
1 Crimson software is a free download from http://www.redlion.net/
100 ohm Pt
alpha = .00385
-200 to 850°C 0.4°C 1.6°C IEC 751
100 ohm Pt
alpha = .00392
-200 to 850°C 0.4°C 1.6°C
no official
standard
120 ohm Nickel
alpha = .00672
-80 to 260°C 0.2°C 0.5°C
no official
standard
INPUT TYPE
10 ohm Copper
alpha = .00427
-100 to 260°C 0.4°C 0.9°C
no official
standard
RANGE
ACCURACY*
(18 to 28°C)
ACCURACY*
(0 to 50°C)
STANDARD
TYPE MODEL NO. DESCRIPTION PART NUMBER
CUB5 CUB5RT
RTD Meter with Reflective Display CUB5RTR0
RTD Meter with Backlight Display CUB5RTB0
Optional Plug-in
Cards
CUB5RLY Single Relay Output Card CUB5RLY0
CUB5SNK Dual Sinking Output Card CUB5SNK0
CUB5COM
RS485 Serial Communications Card CUB5COM1
RS232 Serial Communications Card CUB5COM2
CUB5USB USB Programming Card CUB5USB0
Accessories
MLPS
+12 VDC Micro-Line Power Supply, 85 to 250 VAC source, 400 mA max out MLPS1000
+24 VDC Micro-Line Power Supply, 85 to 250 VAC source, 200 mA max out MLPS2000
CBLPROG RS232 Programming Cable (DB9-RJ11) CBLPROG0
CBPRO Crimson PC Configuration Software for Windows 98, ME, 2000, XP 1 SFCRD200
CBLUSB USB Programming Cable CBLUSB00
