1. DISPLAY: 3 1/2-digit, 0.56" (14.2 mm) high, 7-segment red LED. Decimal
points inserted before 1st, 2nd, or 3rd least significant digits by DIP switch
selection.
2. POWER: 115/230 VAC, switch selectable. Allowable power line variation
±10%, 50/60 Hz, 6 VA.
Isolation: 2300 Vrms for 1 min. between input and supply
Working Voltage: 300 V max., CAT II
3. SIGNAL INPUT:
Range: 0 to 5 Amps AC @ 45 to 400 Hz
Resolution: 2.5 mA
Working Voltage: 300 V max., CAT II
4. ACCURACY: ±(0.5% of reading + 5 digits).
5. OVER-RANGE INDICATION: is indicated by blanking 3 least significant
digits.
6. MAX SHUNT CURRENT: 50 Amps for 1 sec.; 8 Amps continuous.
Caution: In circuits where fault currents can exceed the maximum shunt
current, a fast-blow fuse should be installed in series with the input signal.
Otherwise, a slow blow 8 Amp fuse is recommended that will allow for
start-up over current situations, while still protecting the instrument.
7. ENVIRONMENTAL CONDITIONS:
Operating Temperature: 0° to 60 °C
Storage Temperature: -40° to 80 °C
Operating and Storage Humidity: 85% max. relative humidity (non-
condensing)
Vibration According to IEC 68-2-6: Operational 5 to 150 Hz, in X, Y, Z
direction for 1.5 hours, 2g’s.
Shock According to IEC 68-2-27: Operational 30g’s, 11 msec in 3
directions.
Altitude: Up to 2000 meters
8. RESPONSE TIME TO STEP CHANGE INPUT: 1 sec. nominal
9. READING RATE: 2.5 readings/sec., nominal
10. CERTIFICATIONS AND COMPLIANCES:
SAFETY
UL Recognized Component, File # E179259, UL61010A-1, CSA C22.2 No. 61010-1
Recognized to U.S. and Canadian requirements under the Component
Recognition Program of Underwriters Laboratories, Inc.
UL Listed, File # E137808, UL508, CSA C22.2 No. 14-M95
LISTED by Und. Lab. Inc. to U.S. and Canadian safety standards
Type 4X Enclosure rating (Face only), UL50
IECEE CB Scheme Test Report # 04ME11209-20041018
Issued by Underwriters Laboratories, Inc.
IEC 61010-1, EN 61010-1: Safety requirements for electrical equipment
for measurement, control, and laboratory use, Part 1.
IP65 Enclosure rating (Face only), IEC 529
ELECTROMAGNETIC COMPATIBILITY
Emissions and Immunity to EN 61326: Electrical Equipment for Measurement,
Control and Laboratory use.
Notes:
1. Criterion A: Normal operation within specified limits.
2. Criterion B: Temporary loss of performance from which the unit self-
recovers.
11. CONNECTIONS: High compression cage-clamp terminal block
Wire Strip Length: 0.3" (7.5 mm)
Wire Gage: 30-14 AWG copper wire
Torque: 4.5 inch-lbs (0.51 N-m) max.
12. CONSTRUCTION: This unit is rated for NEMA 4X/IP65 outdoor use.
Installation Category II, Pollution Degree 2. One piece bezel/case. Flame
resistant. Panel gasket and mounting clip included.
13. WEIGHT: 0.65 lbs. (0.24 Kg)
3
G
ENERAL
M
ETER
S
PECIFICATIONS
A
CCESSORIES
UNITS LABEL KIT (PAXLBK)
Each meter has a units indicator with backlighting that can be customized
using the Units Label Kit. The backlight is controlled by a DIP switch.
Class B EN 55011 Emissions
Emissions:
0.5 cycle; 40 % variation
Criterion A EN 61000-4-11 Voltage dip/interruptions
3 V/rms
Criterion A EN 61000-4-6 RF conducted interference
1 kV L-L,
Criterion A EN 61000-4-5 Surge
2 kV signal
2 kV power
Criterion B EN 61000-4-4 Fast transients (burst)
2 kV L&N-E power
10 V/m
Criterion B EN 61000-4-3 Electromagnetic RF fields
8 kV air discharge
4 kV contact discharge
Criterion A EN 61000-4-2 Electrostatic discharge
Immunity to Industrial Locations:
