1.
Connect the analog output signal cable connector to the indicator
base connector. Connect the screw terminal block as follows:
Brown wire:
common wire (-)
Yellow-green wire:
signal (+)
2. Open
the
MENU
, press
OPEN.
3. Select
►Functions
, press
.
4. Select
►Analog output
, press
.
5. Select
0.0 V
to set the value for the 0.0V output signal, press
SET
(If the analog output is ON, take it OFF). Set the low value by
using the arrow buttons. Press
OK
to make the setting.
6. Select
1.0V
to set the value for the 1.0V output signal, press
SET
.
Set the high value by using the arrow buttons. Press
+/-
button to
choose the sign of the value. Press
OK
to make the setting.
7. Select
Analog output on/off
, press
ON
to activate the analog output
and return back to the basic display.
8.
A wire picture sign appears on the upper left corner of the basic
display.
9. To deactivate the analog output function, go to
MENU ►Functions
►Analog output ►Analog output on/off
and press
OFF
.
