Vaisala GM70 User Manual
Page 21
Chapter 4 ______________________________________ Measuring Carbon Dioxide
VAISALA __________________________________________________________
21
0505-222
Figure 2
Properly Connecting the GM70PUMP
The following number refers to Figure 2 above:
1
=
Match the 2 O-rings together with the smooth probe surface to
have a tight connection!
NOTE
Only one pump aspirated system can be connected to the MI70 at a time.
NOTE
When using the pump aspirated system it is recommended to power the
system by using the recharger connected to a wall socket.
NOTE
The battery indicator of the MI70 display does NOT show the actual
recharge level when the pump is in operation.
